Just like PCB business, PCBAMAKE PCB Assembly services also specializes in PCB assembly prototype and small-volume PCBA production, making PCBAMAKE the one-stop destination of boards fabrication and assembly. This arrangement makes your R&D work easy and time-saving.

Our professional engineers and technicians will work closely with you through our customer service people to ensure the best quality and quickest possible lead time. Fulfilling thousands of daily orders from all over the word, we have established ourselves as the leading supplier of PCB and PCB Assembly services for our consistent quality and excellent services.

PCBAMAKE offers one stop turkey PCB assembly services OEM in prototype quantities or low-volume to mid-volume production runs.

We handle the whole process including:

  •   Sourcing components
  •   PCB manufacturing
  •   PCB assembly
  •   Final shipment

We are capable of assembling:

  •   BGA
  •   Micro-BGA
  •   QFN
  •   Other leadless package parts

PCBA in Different Applications

Aerospace PCBA
Robot PCBA
UAV & Drone PCBA
Medical Equipment PCBA
Consumer Electronic PCBA
Industrial Control PCBA
Telecommunication PCBA
New Energy Automobile PCBA
1
Testing Procedures
Various testing methods will be applied to the assembled boards before the final shipment:
  • Visual inspection: general quality check.
  • X-ray Inspection: checks for BGAs, QFN and bare circuit boards.
  • AOI Testing: checks for solder paste, 0201 components, missing components and polarity.
  • ICT (In-Circuit Test).
  • Functional test (Following your test procedures).
2
Inspection Methods
  • AOI Testing:Checks for solder paste
  • Checks for components down to 0201":Checks for missing components, offset, incorrect parts, polarity
  • X-Ray Inspection:X-Ray provides high-resolution inspection
  • BGAs:Micro BGAs
  • Micro BGAs:Bare boards
3
ISO Certification
PCBAMAKE production facilities have passed ISO9001:2015.ISO13485:2016,IPC610,UL,ROHS certification to ensure that we exceed your expectations
  • ISO9001 certified
  • IPC610-D Test specification
  • Pass rate ≥99.5%
  • Quality complaint rate ≤ 0.1%


PCB Assembly service

SMT and Through-Hole Assembly Fine Pitch Component Insertion
Lead free Assembly BGA and QFN Assembly
One-stop PCB Assembly BGA X-Ray Inspection
Prototype PCB Assembly Automated Optical Inspection
PCB Assembly in low volumes PCB testing for functionality
AOI Testing
Checks for solder paste
Checks for components down to 0201"
Checks for missing components, offset, incorrect parts, polarity
X-Ray Inspection
X-Ray provides high-resolution inspection
In-Circuit Testing
In-Circuit Testing is commonly used in conjunction with AOI minimizing functional defects caused by component problems.
Power-up Test
Advanced Function Test
Flash Device Programming
Functional testing
Selective Wave Soldering Conformal Coating
Complete box build Kitting and 3D printing

Pcb assembly Delivery Time

If you are interested in a certain PCBA service,please contact us at poe@pcbamake.com, we will respond if we can do or not within 24 hours

Order Conditions Standard Delivery Date The fastest Delivery Date
Prototype ( <20pcs) 2days 8hours
Small Volume (20-100pcs) 3days 12hours
Medium Volume (100-1000) 6days 24hours
Mass Production (>1000) Depends on BOM Depends on BOM

PCB Assembly Capability

Item Item Name PCBA Capability
1 Lead Time Our assembly time ranges from 24 Hours to a few weeks. Please choose appropriate time option to fit your schedule and budget.
Due to the complexity of how to determine the turn time of PCBA services, our policy is that turn-time begins immediately after all the parts are ready and all the PCB files (Gerber files/other PCB files, etc.,) , Pick & Place PNP file, or XY Data or files in other formats), BOM, and all other necessary data or documents/images/photos are complete for our assembly work.
2 Parts Source
Consigned/kitted We prefer we supply all the parts for the PCBA services for our customers. In this case, please send us all the components with BOM file and detailed packing list indicating item number, customer or manufacturer’s part number and quantity in kit.
Turn-key With our wide and powerful network of parts sourcing, we offer Turn-key PCBA service. We do not mark up on the parts cost. Considering the big price gap between different suppliers, we only source from reliable suppliers who may have no price advantages. We will always ask for your approval before making any decisions.
Partial Turn-key/Combo This is our regular practice which you offer the main devices and components, while we source the rest for you. Just like the Turn-key service, we will ask for your approval on every details of the parts concerning price, quality and availability.
3 Assembly Options We offer Surface Mount (SMT), Through-Hole (THT) and a conbination of both. We also offer single or double-sided placement. We make the SMT and DIP jig for your projects, this jig is one time charge.
4 Types of Solder We offer both leaded and lead-free (RoHS Compliant) assembly services for our customers. Please choose one to best fit your PCB and the parts on the PCB.
5 Stencils We use laser cut stainless steel stencils to ensure high reliability for fine pitch and BGA components. Red ink coating is available upon request.
6 Minimum Order Our minimum is as low as 1pcs. We do not want you to pay for what you do not need indeed to save you money. And for shipping less than 2kgs, we do it for free.
7 Component Size Passive Component: we can accept components as small as 01005, 0201,0402.
BGA: We have the ability to handle BGA of 0.3mm pitch for rigid PCBs and 0.4mm for flex boards with X-ray testing. (The details can be confirmed according to the board design.)
Fine Pitch Parts: we can assemble 0.25mm fine pitch parts.
8 Component Package We accept parts in Reels, Cut Tape, Tube & Tray, Loose Parts and Bulk.
9 Board Dimension Min Board Size: 50mm x 100mm (Boards smaller than this size need to be panelized)
Max Board Size: 250mm x 500mm
10 Board Shape We can assemble boards in Rectangular, Circular and any Odd Shapes. (For shapes other than rectangle, you need to panelize the boards in an array, and add break-away rails at the two longer paralleled edges of the panelized boards to ensure that the boards can be assembled by the machine.)
11 Board Type Rigid boards ,flex and rigid-flex boards, please contact poe@pcbamake.com if your boards are of other materials.
12 Repair & Rework Repair and rework can be difficult, but we do. Our BGA reballing service with which we can safely remove the misplaced BGA, reball it and put it back on the PCB correctly. It is cost-effective. And we repaird the bad boards sometimes without any cost, please feel free to contact us at poe@pcbamake.com
